High Voltage Tester | Non-Contact Electroscope | 380V to 500kV, IP65

This high voltage tester is a non-contact AC electroscope that checks for the presence of voltage by induction, with 8 selectable ranges from 380V up to 500kV and a sound and light alarm. Set the dial to the system voltage and the red lamps and buzzer trigger when the detected voltage exceeds that setting; fit it to an insulating rod for high voltage work. Features and Benefits - 8 voltage ranges - 380V, 6kV, 10kV, 27.5kV, 35kV, 110kV, 220kV and 500kV on one rotary dial - Non-contact inductive sensing - no need to touch the conductor, so you stay clear of live parts - Sound and light alarm - two red lamps and a buzzer signal when voltage above the selected range is detected - Self-test position - TEST on the dial lets you check the alarm before and after use - IP65 sealed, shockproof housing - suited to harsh working environments - Fits most insulating rods - plus a low battery lamp that lights when the 9V battery drops to about 5.5V Applications - Checking for AC high and low voltage on cables and equipment - Locating live high voltage cables and tracing wires on site - Detecting residual or induced voltage and checking grounded equipment - Power maintenance, railway circuits, industrial and mining sites Note: For trained personnel only. Self-test before and after each check, keep the safe approach distance for the system voltage, disconnect and isolate the supply before work, and confirm zero volts with a suitably rated tester before touching. The 9V battery and the insulating rod are not included.
