Firewall Appliance Mini PC | 6x 2.5G LAN | Intel Ultra 7 2xDDR5

Name: Firewall Appliance Mini PC | 6x 2.5G LAN | Intel Ultra 7 2xDDR5
Brand: Compel Group
SKU: SING-00226
Price: 1200.99 GBP
Availability: InStock
Rating: 5 (1 reviews)

Stock Nr:

SKU:

Firewall Appliance Mini PC | 6x 2.5G LAN | Intel Ultra 7 2xDDR5 - Image 1

1 / 5

£1,200.99inc VAT

Size12 optionsSelect an option

Quantity

Firewall Appliance Mini PC | 6x 2.5G LAN | Intel Ultra 7 2xDDR5

£1,200.99

Fast Shipping

Secure Payment

Easy Returns

Good to know

Questions about this product

Are the Intel i226-V network ports recognised by OPNsense and pfSense?: Yes, current releases of both platforms include native drivers for the Intel i226-V 2.5GbE chipset. All six RJ45 ports run at full 2.5Gbps speed without needing manual driver patches.
How much memory and storage can this appliance hold?: The board has two DDR5 SODIMM slots that accept up to 96GB of 4800MHz or 5600MHz RAM. For drives, it fits two M.2 2280 NVMe SSDs and one 2.5-inch SATA hard drive or SSD.
Can I use this machine to run Proxmox with a virtualised firewall?: Yes, the 16-core Intel Ultra processor and high RAM capacity easily handle Proxmox VE. You can pass the physical Intel network ports directly through to an OPNsense virtual machine while hosting storage services alongside it.

Computers & Tablets spec sheet (PDF)

Get a one-page sheet with full description, specifications, technical details, FAQs, price & SKU - handy to save, print, or share.

Not sure which one?

Compare with similar products

The same kind of product, in stock, in a similar price range.

This product: £1,200.99 · 5.0

This product

Port panel of Firewall Appliance Mini PC featuring USB, Type-C, display connections, and top heatsink.

Firewall Appliance Mini PC | 6x 2.5G LAN | Intel Ultra 7 2xDDR5

Price: £1,200.99
Rating: 5.0(1)
Sold: 2+
Stock: In stock

You're viewing this

Alternative

Front panel of a Firewall Appliance showing various USB, display, Type-C, and network card ports.

Firewall Appliance | 6x 2.5GbE & Optional SFP | Intel Core Ultra

Price: £1,211.99
Rating: 5.0(4)
Sold: 27+
Stock: In stock

View

Alternative

Front and side perspective of a black 1U Firewall Appliance showing network ports and cooling vents.

1U Firewall Appliance | Intel N97/N150 | 4x 2.5GbE LAN

Price: £718.99
Rating: 5.0(2)
Sold: 3+
Stock: In stock

View

Alternative

Firewall Appliance Mini PC | Intel N150 | Up to 10G SFP+ & 8x 2.5G

Price: £604.99
Rating: 5.0(7)
Sold: 71+
Stock: In stock

View

Alternative

1U Firewall Appliance | Intel N150 4x 2.5GbE | 10G SFP+ Options

Price: £861.99
Rating: 4.7(3)
Sold: 17+
Stock: In stock

View

Alternative

Front and rear panels of a Firewall Appliance Mini PC with Ethernet, USB, and power ports.

Firewall Appliance Mini PC | Dual 10G AQC113 4x 2.5GbE | 1U Rack Router

Price: £516.99
Rating: Not rated
Sold: -
Stock: In stock

View

Alternative

Front panel of the Firewall Appliance Mini PC showing USB, Type-C, SIM, and console ports below heatsink fins.

Firewall Appliance Mini PC | 4x 2.5G LAN | Optional 10G SFP+

Price: £636.99
Rating: Not rated
Sold: 6+
Stock: In stock

View

Alternative

Firewall Appliance Mini PC showing top heatsink fins, power button, console port, and USB ports.

Firewall Appliance Mini PC | Dual 10G SFP+ & 10GbE | Dual 2.5GbE LAN

Price: £816.99
Rating: Not rated
Sold: 4+
Stock: In stock

View

Alternative

Rear panel of Firewall Appliance Mini PC featuring multiple Ethernet ports, console port, and power input.

Firewall Appliance Mini PC | 2x 10G SFP+ & 4x 2.5GbE or 8x 2.5GbE | DDR5

Price: £787.99
Rating: Not rated
Sold: 2+
Stock: In stock

View

Compare options

More Computers & Tablets

All Computers & Tablets

Explore the range

Popular in Electronics & Components

Browse Electronics & Components

Heat Shrink Tubing Kit | 2:1 Shrink Ratio | 164-328 Pieces, 5 Colors, 8 Sizes

4.9

£25.99

Double-Sided Prototype PCB | 5x7cm Universal Board | DIY Electronics

4.9

£31.99

Hard Drive for PS4 & Xbox | 1TB USB 3.0 Storage | 2.5-Inch HDD

4.9(4.2K)

£89.99

Cat8 Ethernet Cable | SFTP 40Gbps 2000MHz | Router Modem Patch Lead

4.9(2.0K)

£31.99

Heat Shrink Tubing | PVC Flat Battery Wrap for 18650 Cells | 100-Piece Assortment

4.9

£27.99

RCBO Circuit Breaker | 230V 1P+N | Overcurrent & Leakage Protection

4.9

£52.99

M.2 NVMe SSD to PCIe Adapter | 16Gbps PCIe 4.0 x1 Expansion Card

4.9(2.1K)

£36.99

Flash Drive | 64GB Wooden Bamboo Memory Stick | Custom Logo Wedding Gift

4.9(353)

£38.99

SATA III Cable | 50cm SATA 3.0 6Gbps | SSD & HDD Desktop PC Build

4.9(1.3K)

£30.99

12V 5A AC/DC Power Adapter | Universal Regulated Switching Power Supply for LED & CCTV Systems

4.9

£47.99

Micro SD Card 256GB | UHS-1 Class 10 Speed | For Smartphone & PC

4.8(9.9K)

£91.99

2.5-inch USB 3.0 HDD/SSD Enclosure | 5Gbps SATA Drive Case

4.8(6.4K)

£52.99

Complete the set

Accessories & add-ons

SATA Cable 8-Pack | 6Gbps Right-Angle | 0.5M for RAID & Bitcoin Rigs

5.0(81)

£35.99

Professional-Grade Cable Management Kit | 500-Piece Nylon Zip Ties | Heavy-Duty Self-Locking Straps

5.0

£37.99

Push-In Wire Connectors | 5-Pack | Fast, Secure Electrical Splicing Terminal Blocks

4.9

£24.99

M.2 SSD Hard Drive Caddy Heatsink | NVMe 2280 Aluminum Cooler | For PS5 & PC

4.9(1.6K)

£33.99

90-Degree SATA Cable | Locking Latch Connectors | SATA III 6.0 Gbps 12-Pack

4.9(555)

£45.99

Drive Caddy | 2.5 to 3.5 inch SSD Mounting Bracket | For Desktop PC Bay

4.9(292)

£30.99

Professional-Grade Solder Wire | 40g Rosin Core | 183°C Melting Point for Precision Electronics Work

4.9

£25.99

Drive Caddy | 2.5 to 3.5 Inch Bay Adapter | For SSD & HDD Mounting

4.9(311)

£41.99

JST SM 2-Pin Connector Kit | 10-Pair Set for LED Strip & Tape Lighting

4.9

£30.99

2.8mm Electrical Connector Kit | 2-9 Pin Automotive Terminals | Waterproof Wire Harness Plug Set

4.9

£25.99

Dell Hard Drive Caddy | 2.5-inch SAS/SATA Tray | For PowerEdge R730 R630

4.9(63)

£43.99

SATA Cable with Locking Latch | 6Gbps SATA III Data | For Secure HDD SSD Builds

4.9(239)

£52.99

Equipped with latest-generation Intel Core Ultra silicon, this firewall appliance mini pc brings enterprise compute power to compact networking. Six 2.5-gigabit Intel i226-V controllers and fast DDR5 memory handle multi-gigabit fiber feeds, aggressive IDS/IPS filtering, and multi-tenant virtualization effortlessly. Features and Benefits - Six Intel i226-V 2.5GbE ports - Gives you stable multi-gigabit throughput on BSD systems without the driver drops of non-Intel chips. - Intel Core Ultra processor architecture - Powers real-time Zenarmor and Suricata packet inspection across symmetrical multi-gigabit connections. - Dual DDR5 memory slots - Speeds up memory-intensive virtual machines, heavy network caching, and fast local database lookups. - Solid metal cooling fins - Keeps the internal components at stable operating temperatures during prolonged high-throughput network bursts. Applications - High-speed home lab server running Proxmox VE to host an OPNsense router, Pi-hole, and local containers together. - Multi-gigabit fiber gateway for creative workspaces needing line-rate WireGuard VPN access alongside 2.5Gbps LAN transfers. - Compact network edge device for branch locations running full deep packet inspection without dedicating a full-sized rack.

Voltage: 226V. Processor: Intel Ultra. Type: Embedded Computer. Dimensions: 168 x 131 x 64 mm. Weight: 1.1 kg. Chassis Material: CNC Aluminum Alloy Body. Power Supply: DC 19V / 4.74A (90W Adapter). Network Interfaces: 6x Intel I226-V 2.5GbE RJ45 LAN. Storage Interfaces: 2x M.2 NVMe PCIe 4.0 x4 (2280), 1x SATA 3.0. Operating System Compatibility: OPNsense, pfSense-CE, Proxmox VE, ESXi, Linux. Cooling System: Active Copper Heatpipe with PWM Silent Fan. Form Factor: Ultra-Compact Mini PC Firewall Appliance. Hardware Encryption & AI: Intel AES-NI, Intel AI Boost NPU. Memory Support: 2x DDR5 SO-DIMM Slots, Up to 64GB 5600MHz. Model: H15. Processor Options: Intel Core Ultra 9 185H (16C/22T) / Ultra 7 155H (16C/22T). Video & Expansion I/O: 1x HDMI 2.1, 1x DP 1.4, 1x Type-C (Thunderbolt 4 / USB4), 4x USB 3.2. Q: What network controller and memory standards does this platform use? A: It includes six Intel I226-V 2.5GbE ports for multi-gigabit throughput. The motherboard supports dual DDR5 memory slots alongside Intel Core Ultra 7 155H or Ultra 9 185H processors.. Q: How does the metal case maintain performance under full load? A: The compact aluminum body features finned surface panels that dissipate thermal loads directly into ambient air. Internal heatpipes pull wattage off the chip so it runs stable without thermal throttling.. Q: Can I run virtualization and firewall operating systems on this unit? A: Yes, the hardware boots OPNsense, OpenWrt, TrueNAS, and hypervisors like Proxmox VE. The combination of DDR5 RAM and 16-core processing lets you host virtual network functions side by side.. Q: What kind of warranty comes with this firewall appliance mini pc? A: The unit includes a one-year hardware warranty from the factory. If you experience hardware defects under normal operating conditions, the seller provides replacement parts or service.. Q: What makes this system worth the upgrade over older mini routers? A: The 2.5GbE ports eliminate standard Gigabit bottlenecks on fast fiber internet plans. It combines a high-thread Meteor Lake processor with NVMe storage, handling firewall tasks and local NAS storage simultaneously..
