Firewall Appliance Mini PC | 2x 10G SFP+ or 8x 2.5G LAN | Proxmox Server

Name: Firewall Appliance Mini PC | 2x 10G SFP+ or 8x 2.5G LAN | Proxmox Server
Brand: Compel Group
SKU: SING-00281
Price: 787.99 GBP
Availability: InStock
Rating: 5 (3 reviews)

Stock Nr:

SKU:

Firewall Appliance Mini PC | 2x 10G SFP+ or 8x 2.5G LAN | Proxmox Server - Image 1

1 / 6

£787.99inc VAT

Size12 optionsSelect an option

Quantity

Firewall Appliance Mini PC | 2x 10G SFP+ or 8x 2.5G LAN | Proxmox Server

£787.99

Fast Shipping

Secure Payment

Easy Returns

Good to know

Questions about this product

What network interface chips are fitted to the 10G and 2.5G ports?: The unit features two 10G SFP+ optical cages alongside eight dedicated 2.5GbE RJ45 ethernet ports. That gives you 10 separate physical interfaces to split WAN, LAN, DMZ, and management subnets.
Can this unit route full 10Gbps line rate through pfSense or OPNsense?: Yes, but you will want the Core i5 or i7 processor options to process high-throughput 10G firewall rules and NAT translation. The 12th Gen Core chips give you up to 12 cores and 16 threads, which easily handles 10Gbps routing without bottlenecking.
Can I use 10G copper RJ45 SFP+ transceivers in this chassis?: You can, but optical fibre SFP+ modules or direct attach copper (DAC) cables are strongly recommended instead. RJ45 10G transceivers draw roughly 2.5W to 3W each and create significant heat inside an enclosure without forced fan cooling.

Computers & Tablets spec sheet (PDF)

Get a one-page sheet with full description, specifications, technical details, FAQs, price & SKU - handy to save, print, or share.

Not sure which one?

Compare with similar products

The same kind of product, in stock, in a similar price range.

This product: £787.99 · 5.0

This product

Rear view of Firewall Appliance Mini PC showing RJ45 Ethernet, SFP+ ports, and DC power input.

Firewall Appliance Mini PC | 2x 10G SFP+ or 8x 2.5G LAN | Proxmox Server

Price: £787.99
Rating: 5.0(3)
Sold: 21+
Stock: In stock

You're viewing this

Alternative

Front panel of a Firewall Appliance showing various USB, display, Type-C, and network card ports.

Firewall Appliance | 6x 2.5GbE & Optional SFP | Intel Core Ultra

Price: £1,211.99
Rating: 5.0(4)
Sold: 27+
Stock: In stock

View

Alternative

Firewall Appliance Mini PC | 2x 10G & 2x 2.5G RJ45 | Intel N150 / i3-N305

Price: £690.99
Rating: 5.0(1)
Sold: 25+
Stock: In stock

View

Alternative

Front and side perspective of a black 1U Firewall Appliance showing network ports and cooling vents.

1U Firewall Appliance | Intel N97/N150 | 4x 2.5GbE LAN

Price: £718.99
Rating: 5.0(2)
Sold: 3+
Stock: In stock

View

Alternative

Firewall Appliance Mini PC | Intel N150 | Up to 10G SFP+ & 8x 2.5G

Price: £604.99
Rating: 5.0(7)
Sold: 71+
Stock: In stock

View

Alternative

1U Firewall Appliance | Intel N150 4x 2.5GbE | 10G SFP+ Options

Price: £861.99
Rating: 4.7(3)
Sold: 17+
Stock: In stock

View

Alternative

Rear panel of Firewall Appliance Mini PC featuring multiple Ethernet ports, console port, and power input.

Firewall Appliance Mini PC | 2x 10G SFP+ & 4x 2.5GbE or 8x 2.5GbE | DDR5

Price: £787.99
Rating: Not rated
Sold: 2+
Stock: In stock

View

Alternative

1U Firewall Appliance | Intel Core i5/i7 | 6x 2.5GbE & Up to 4x 10G SFP+

Price: £1,222.99
Rating: Not rated
Sold: 3+
Stock: In stock

View

Alternative

4x 2.5G Firewall Appliance Mini PC | DDR5 NVMe | Proxmox ESXi Virtual Server

Price: £604.99
Rating: Not rated
Sold: -
Stock: In stock

View

Compare options

More Computers & Tablets

All Computers & Tablets

Explore the range

Popular in Electronics & Components

Browse Electronics & Components

Heat Shrink Tubing Kit | 2:1 Shrink Ratio | 164-328 Pieces, 5 Colors, 8 Sizes

4.9

£25.99

Double-Sided Prototype PCB | 5x7cm Universal Board | DIY Electronics

4.9

£31.99

Hard Drive for PS4 & Xbox | 1TB USB 3.0 Storage | 2.5-Inch HDD

4.9(4.2K)

£89.99

Cat8 Ethernet Cable | SFTP 40Gbps 2000MHz | Router Modem Patch Lead

4.9(2.0K)

£31.99

Heat Shrink Tubing | PVC Flat Battery Wrap for 18650 Cells | 100-Piece Assortment

4.9

£27.99

RCBO Circuit Breaker | 230V 1P+N | Overcurrent & Leakage Protection

4.9

£52.99

M.2 NVMe SSD to PCIe Adapter | 16Gbps PCIe 4.0 x1 Expansion Card

4.9(2.1K)

£36.99

Flash Drive | 64GB Wooden Bamboo Memory Stick | Custom Logo Wedding Gift

4.9(353)

£38.99

SATA III Cable | 50cm SATA 3.0 6Gbps | SSD & HDD Desktop PC Build

4.9(1.3K)

£30.99

12V 5A AC/DC Power Adapter | Universal Regulated Switching Power Supply for LED & CCTV Systems

4.9

£47.99

Micro SD Card 256GB | UHS-1 Class 10 Speed | For Smartphone & PC

4.8(9.9K)

£91.99

2.5-inch USB 3.0 HDD/SSD Enclosure | 5Gbps SATA Drive Case

4.8(6.4K)

£52.99

Complete the set

Accessories & add-ons

SATA Cable 8-Pack | 6Gbps Right-Angle | 0.5M for RAID & Bitcoin Rigs

5.0(81)

£35.99

Professional-Grade Cable Management Kit | 500-Piece Nylon Zip Ties | Heavy-Duty Self-Locking Straps

5.0

£37.99

Push-In Wire Connectors | 5-Pack | Fast, Secure Electrical Splicing Terminal Blocks

4.9

£24.99

M.2 SSD Hard Drive Caddy Heatsink | NVMe 2280 Aluminum Cooler | For PS5 & PC

4.9(1.6K)

£33.99

90-Degree SATA Cable | Locking Latch Connectors | SATA III 6.0 Gbps 12-Pack

4.9(555)

£45.99

Drive Caddy | 2.5 to 3.5 inch SSD Mounting Bracket | For Desktop PC Bay

4.9(292)

£30.99

Professional-Grade Solder Wire | 40g Rosin Core | 183°C Melting Point for Precision Electronics Work

4.9

£25.99

Drive Caddy | 2.5 to 3.5 Inch Bay Adapter | For SSD & HDD Mounting

4.9(311)

£41.99

JST SM 2-Pin Connector Kit | 10-Pair Set for LED Strip & Tape Lighting

4.9

£30.99

2.8mm Electrical Connector Kit | 2-9 Pin Automotive Terminals | Waterproof Wire Harness Plug Set

4.9

£25.99

Dell Hard Drive Caddy | 2.5-inch SAS/SATA Tray | For PowerEdge R730 R630

4.9(63)

£43.99

SATA Cable with Locking Latch | 6Gbps SATA III Data | For Secure HDD SSD Builds

4.9(239)

£52.99

Built for fast local networks, this multi-port firewall pairs either two 10G SFP+ slots and four 2.5G Ethernet jacks or eight 2.5G Ethernet jacks with Intel 12th Gen processors. The box pushes line-rate traffic, isolates busy subnetworks, and runs hypervisor tasks 24/7 without overheating. Features and Benefits - Intel Core i3, i5, and i7 options - Brings up to 12 cores to chew through 10Gbps filtering, IDS rules, and encrypted VPN tunnels. - Dual 10G SFP+ cages with four 2.5G ports, or eight 2.5G ports - Links straight to fiber switches and fast local gear without add-in cards. - Thick aluminum heatsink body - Moves heat away from the CPU and optical modules to protect parts during continuous runs. - Two DDR4 RAM slots and dual SATA plugs - Holds enough memory and disk space for virtual firewalls, storage pools, and network tests. Applications - Main OPNsense or pfSense gateway routing 10Gbps fiber internet feeds. - Proxmox home lab server mapping physical network ports straight to virtual machines. - Core routing appliance for test benches moving large file transfers across VLANs.

Processor: Intel Core i7-1260P / i5-1235U / i3-1215U / 8505. Storage Interface: 2 x SATA. Network Interfaces: 2 x 10G SFP+, 8 x 2.5GbE RJ45 LAN. Device Type: Firewall Appliance Mini PC. Form Factor: Mini PC. Supported Systems: Proxmox, pfSense, Linux, Windows. Chassis Dimensions: 217 x 154 x 62 mm. Weight: 1.45 kg. Enclosure Material: Heavy-Duty Extruded Aluminum. Power Supply: DC 12V-19V input. High-Speed SFP Ports: 2x 10GbE SFP+ optical cage slots. Ethernet LAN Ports: 8x 2.5GbE RJ45 Intel i226-V Gigabit LAN ports. Storage Interfaces: 1x M.2 2280 NVMe SSD slot + 2x SATA 3.0 ports. Operating System Support: Proxmox VE, pfSense, OPNsense, ESXi, Ubuntu Server. Cooling Design: Active/Passive Hybrid with Aluminum Alloy Heatsink Enclosure. Form Factor: Multi-Port 1U/Desktop Firewall Appliance. Memory Support: 2x DDR4 3200MHz SO-DIMM slots (up to 64GB). Processor Options: Intel Core i7-1260P / i5-1235U / i3-1215U / Celeron 8505 (12th Gen). Virtualization Support: Intel VT-x, VT-d, AES-NI hardware encryption. Q: What network throughput can I expect from the physical interfaces? A: You get eight 2.5 GbE RJ45 jacks alongside two 10 GbE SFP+ optical cages. That layout provides up to 40 Gbps of total raw bandwidth for routing, switching, and virtualization.. Q: How does the build handle sustained CPU loads during continuous operation? A: The chassis is made of extruded aluminum ribs that distribute heat across the entire outer shell. An internal fan header is also available if you need forced airflow for hot server closets.. Q: Can I use this unit as a high-throughput firewall appliance mini pc? A: Yes, it functions smoothly as a firewall appliance mini pc running Proxmox VE, ESXi, or bare-metal routing software. The multiple ports let you isolate separate VLANs and physical subnets without needing an external managed switch.. Q: What is the warranty period for this multi-port server? A: It comes with a standard 12-month manufacturer warranty from the date of delivery. The policy covers mainboard failures, bad network controllers, and defective power supplies.. Q: What makes this machine a practical investment compared to standard rackmount servers? A: It combines ten high-speed network interfaces into a box that fits on a desk. You save money on power draw and fan noise while getting 12th Gen Intel multi-core processing..
