Solar DC Circuit Breaker | 2-Pole 1000V MCB | 3A-63A for PV System Protection

Engineered for high-voltage DC systems, the TOMZN TOB7Z-63 2P DC 1000V solar mini circuit breaker provides reliable overcurrent and short-circuit protection. Its 1000V DC rating and 10kA breaking capacity ensure robust safety for demanding photovoltaic applications, available in current ratings from 3A to 63A for precise system matching. Features and Benefits - 1000V DC Rated Voltage - Provides superior protection for high-voltage solar arrays, exceeding the requirements of many residential and commercial PV systems. - 10kA Breaking Capacity - Ensures the MCB can safely interrupt high fault currents, protecting expensive inverters and wiring from damage. - Compact 2-Pole Design - Saves valuable space in combiner boxes and distribution boards while providing complete isolation of both DC poles. - Wide Current Range (3A-63A) - Offers precise protection for various system components, from small branch circuits to main array feeders. - Dedicated DC Arc Extinguishing - Specifically designed to quench DC arcs effectively, a critical safety feature not found in standard AC breakers. - DIN Rail Mountable - Allows for quick, secure, and standardized installation in any compatible electrical enclosure. Applications - PV String and Combiner Box Protection - Safeguards individual solar panel strings and combines multiple strings before the inverter. - Battery Bank and Charge Controller Circuits - Protects the DC side of energy storage systems and charge control equipment. - Off-Grid and Hybrid Solar Systems - Essential component for DC distribution in standalone or backup power installations. - Commercial Solar Array Sub-Circuits - Ideal for managing and protecting sections of larger-scale photovoltaic installations. Note: Always ensure proper system design and that installation complies with all local electrical codes and standards. Select the correct current rating for your specific circuit requirements.
