What kind of bending jobs is this hydraulic press brake best for?

This 130-ton hydraulic press brake is ideal for bending metal plates up to 3200mm long with high precision. It can handle mild steel up to 6mm thick, making it suitable for professional fabrication and manufacturing tasks.

What is the maximum thickness of steel this press brake can bend?

This press brake has a 130-ton bending force and a 3200mm bending length. It can effectively bend mild steel plates up to 6mm thick, providing consistent accuracy of ±0.1 mm.

What kind of power supply does this machine need?

The hydraulic press brake requires a 3-phase AC power supply. It operates on either 380V or 415V at 50Hz, with a motor power of 15 kW. The oil tank capacity is 250 litres.

Hydraulic Press Brake | 130-Ton Capacity | 3200mm Bending Length | DA53T CNC Controller

Name: Hydraulic Press Brake | 130-Ton Capacity | 3200mm Bending Length | DA53T CNC Controller
Brand: Compel
SKU: MANU-00166
Price: 14959.99 USD
Availability: InStock

Stock #:TBS-04487

SKU:MANU-00166

Hydraulic Press Brake | 130-Ton Capacity | 3200mm Bending Length | DA53T CNC Controller - Image 1

1 / 6

$14,959.99

Ships to United States · standard est. 10-20 business days

Free standard shipping on orders over $59 (under 2kg). Express available at checkout.

Premium CNC 130T3200mm Press Brake Plate Metal Hydraulic Bending Machine Delem DA53T Controller. Quality construction with reliable performance for professional and home use....

Quantity

Hydraulic Press Brake | 130-Ton Capacity | 3200mm Bending Length | DA53T CNC Controller

$14,959.99

Fast Shipping

Secure Payment

Easy Returns

Good to know

Questions about this product

What kind of bending jobs is this hydraulic press brake best for?: This 130-ton hydraulic press brake is ideal for bending metal plates up to 3200mm long with high precision. It can handle mild steel up to 6mm thick, making it suitable for professional fabrication and manufacturing tasks.
What is the maximum thickness of steel this press brake can bend?: This press brake has a 130-ton bending force and a 3200mm bending length. It can effectively bend mild steel plates up to 6mm thick, providing consistent accuracy of ±0.1 mm.
What kind of power supply does this machine need?: The hydraulic press brake requires a 3-phase AC power supply. It operates on either 380V or 415V at 50Hz, with a motor power of 15 kW. The oil tank capacity is 250 litres.

Manufacturing & CNC spec sheet (PDF)

Get a one-page sheet with full description, specifications, technical details, FAQs, price & SKU - handy to save, print, or share.
