Can I use this capacitor with a 220V motor?

Yes, this capacitor is rated for 250V AC, so it's compatible with 220V AC systems. Its maximum overload voltage is 330 VAC, providing a safety margin for stable operation. It operates at both 50Hz and 60Hz frequencies.

How do I choose the right microfarad (uF) value for my pump?

This CBB60 motor run capacitor comes in multiple standard values: 30µF, 35µF, 40µF, and 50µF. You should match the µF value to the original capacitor in your air compressor, water pump, or washing machine. A ±5% capacitance tolerance is standard for this type.

What is this capacitor made from for durability?

The case is made from flame-retardant plastic (UL94-V0) and the dielectric is metallized polypropylene film. Terminals are zinc-plated steel or brass for reliable connections. It's sealed with epoxy resin and designed for an expected service life of over 100,000 hours at rated conditions.

Professional-Grade CBB60 Motor Run Capacitor | 250V AC | 30-50uF | For Air Compressor & Water Pump

Name: Professional-Grade CBB60 Motor Run Capacitor | 250V AC | 30-50uF | For Air Compressor & Water Pump
Brand: Compel
SKU: INDU-00077
Price: 21.95 USD
Availability: InStock

Stock #:TBS-03092

SKU:INDU-00077

Professional-Grade CBB60 Motor Run Capacitor | 250V AC | 30-50uF | For Air Compressor & Water Pump - Image 1

1 / 6

$21.95

Ships to United States · standard est. 10-20 business days

Free standard shipping on orders over $59 (under 2kg). Express available at checkout.

Premium AC 250V 30uF 35uF 40uF 50uF CBB60 Motor Run Capacitor with Terminal M8 Fixing Stud for Air Compressor Water Pump Washing Machine. Quality construction with reliable performance for professiona...

SpeedSelect an option

Quantity

Professional-Grade CBB60 Motor Run Capacitor | 250V AC | 30-50uF | For Air Compressor & Water Pump

$21.95

Fast Shipping

Secure Payment

Easy Returns

Good to know

Questions about this product

Can I use this capacitor with a 220V motor?: Yes, this capacitor is rated for 250V AC, so it's compatible with 220V AC systems. Its maximum overload voltage is 330 VAC, providing a safety margin for stable operation. It operates at both 50Hz and 60Hz frequencies.
How do I choose the right microfarad (uF) value for my pump?: This CBB60 motor run capacitor comes in multiple standard values: 30µF, 35µF, 40µF, and 50µF. You should match the µF value to the original capacitor in your air compressor, water pump, or washing machine. A ±5% capacitance tolerance is standard for this type.
What is this capacitor made from for durability?: The case is made from flame-retardant plastic (UL94-V0) and the dielectric is metallized polypropylene film. Terminals are zinc-plated steel or brass for reliable connections. It's sealed with epoxy resin and designed for an expected service life of over 100,000 hours at rated conditions.

Industrial Electrical Components spec sheet (PDF)

Get a one-page sheet with full description, specifications, technical details, FAQs, price & SKU - handy to save, print, or share.

Not sure which one?

Compare industrial electrical components

This product

CBB60 motor run capacitor with M8 stud, rated 250V and 30uF to 50uF, for air compressor, water pump, and washing machine motor

Professional-Grade CBB60 Motor Run Capacitor | 250V AC | 30-50uF | For Air Compressor & Water Pump

Price$21.95

RatingNot rated

Sold11+

Stock In stock

You're viewing this

Alternative

CBB60 450VAC motor run capacitor with 4-pin double insert, available in 4UF to 60UF ratings for electric motor replacement.

Professional-Grade CBB60 Motor Run Capacitor | 450VAC | 4-60µF Range | 4-Pin Double Insert

Price$17.99

Rating4.9

Sold1,000+

Stock In stock

View

Alternative

Uxcell CBB60 12uF 450V AC run capacitor with two wires, cylindrical metal case for air compressor and water pump motors.

Professional-Grade 12uF 450V AC Run Capacitor | CBB60 Motor Start for Air Compressor & Water Pump

Price$22.95

Rating4.5

Sold3+

Stock In stock

View

Alternative

CBB60 run capacitor for motors, 12UF to 35UF, with durable metal casing and insulated terminals for air compressor and water pump applications.

Professional-Grade CBB60 Run Capacitor | 12-35µF for Air Compressor & Pump Motors | Durable Motor Start

Price$47.95

RatingNot rated

Sold9+

Stock In stock

View

Alternative

CBB65 450V AC motor start capacitor for air conditioner compressors, available in 20uF to 80uF capacitance ratings with durable metal casing.

CBB65 Motor Run Capacitor | 450V AC | 20-80uF Range for HVAC & Compressor Systems

Price$11.99

Rating4.4

Sold41+

Stock In stock

View

Alternative

ASEMI CD60 motor run capacitor, 300 microfarads 450VAC, with durable metal case and insulated terminals for industrial machinery.

Professional-Grade CD60 Motor Start Capacitor | 300µF 450VAC | Heavy-Duty HVAC & Compressor Replacement

Price$24.95

RatingNot rated

Sold1+

Stock In stock

View

Compare options

More Industrial Electrical Components

All Industrial Electrical Components

Digital PID Temperature Controller | Universal Sensor Input | 1300°C

5.0(11)

$31.95

12mm Latching Push Button Switch | IP67 Waterproof & Self-Locking | Industrial Metal Electrical Switch

5.0

$11.99

DIN Rail Surge Protector | 2-Pole DC 1000V 40KA | Home & Solar System Protection

5.0

$23.95

DIN Rail Terminal Block | 80-500A Power Distribution | Single-Pole Junction Box

5.0

$39.95

TB Series Terminal Block | 600V 15A Dual-Row Barrier | 3-20 Position Screw Connector

5.0

$10.99

Waterproof Micro Limit Switch | 10A 250V Capacity | AZ-7312 Series | Compact Roller Lever Actuator

5.0

$25.95

12mm Push Button Switch | Momentary & Latching Modes | Premium Tactile Control

5.0

$14.99

-5%

DIN Rail Terminal Blocks | 2.5mm² Push-In Wire Connectors for Reliable Branching & Measurement

5.0

$15.99$16.79

Solid State Relay Module | SSR-25DA/40DA/40AA | 10A-120A | Precision Temperature Control

5.0

$26.95

16mm Self-Resetting Push Button Switch | 4-Color LED Illumination | 2-Pin & 4-Pin Models

5.0

$12.99

TUYA WiFi/ZigBee MCB Smart Circuit Breaker Over Current Under Voltage Protection Power Metering 1-63A Remote Control Switch

4.9

$45.95

-77%

Rocker Switch | ON-OFF Power Control | 16A/250VAC Rated for Marine & Electrical Equipment

5.0

$17.99$77.06

Explore the range

Popular in Industrial & Machinery

Browse Industrial & Machinery

-28%

Electric Fabric Cutter | Round-Knife Cloth Slitting Machine | YJ-110C Hand-Push Design

5.0

$189.99$264.96

Push-to-Connect Air & Water Fittings | 4mm-12mm OD | Quick-Release Hose Couplings

4.9

$5.95

Fitting | 304 Stainless Steel Compression | 1/2 NPT Union

4.9(49)

$2.49

Complete the set

Accessories & add-ons

Sensor Protection Sleeve | Stainless Steel Blind Tube | 6mm

5.0(11)

$39.95

Motion Sensor Bracket | Automatic IR Lamp Holder | 110-240V AC

4.8(196)

$16.99

Soil Moisture NPK Sensor | 7-in-1 Agricultural Probe Accessory

4.8(25)

$26.95

Arduino Raspberry Pi Sensor Kit (45pc) | Modules for UNO R3 MEGA2560

4.7(58)

$47.95

Reflector Plate | Photoelectric Sensor Accessory | TD Series

4.7(23)

$12.99

Load Cell ADC Module | 24-Bit HX711 Sensor Accessory

4.4(21)

$1.49

Bending Strain Gauge Amplifier Module | Sensor Accessories UK

$5.95

Case Material: Aluminum. Terminal Material: Electroplated Steel. Rated Voltage: 250 VAC. Maximum Overload Voltage: 330 VAC. Capacitance: 30 µF, 35 µF, 40 µF, 50 µF. Capacitance Tolerance: ±5%. Capacitor Type: Motor Run. Climatic Category: 40/70/21. Dielectric Type: CBB60 (Metallized Polypropylene Film). Endurance: ≥ 30,000 hours at rated voltage and temperature. Frequency: 50/60 Hz. Maximum Overload Current: 1.3 x Rated Current. Operating Temperature Range: -40°C to +70°C. Safety Standard: IEC 60252-1. Sealing: Epoxy Resin. Terminal Type: M8 Fixing Stud. Case Material: Flame-Retardant Plastic (UL94-V0). Dielectric Material: Metallized Polypropylene Film. Terminal Material: Zinc-Plated Steel or Brass. Rated Voltage: 250V AC. Capacitance Range: 30µF, 35µF, 40µF, 50µF (Multiple Standard Values). Maximum Operating Temperature: +70°C. Minimum Operating Temperature: -40°C. Operating Frequency: 50/60 Hz. Safety Standard: IEC 60252-1, Class P0 (Non-Fuse Protected). Capacitance Tolerance: ±5% (Standard for CBB60). Climatic Category: 40/70/21 (IEC 60252-1). Dissipation Factor (tan δ): ≤ 0.002 (at 20°C, 50Hz). Expected Service Life: ≥ 100,000 hours at rated conditions. Insulation Resistance: ≥ 3000 MΩ·µF (at 20°C, 500V DC). Lead Configuration: Dual-Terminal, Single-Phase. Mounting Method: Stud Mount via M8 Terminal. Product Type: CBB60 Motor Run Capacitor. Protection Class: IP00 (Open Construction). Rated Duty Cycle: Continuous Duty. Self-Healing Property: Yes (Inherent to Metallized Film). Terminal Type: M8 Threaded Stud Fixing. Q: What are the physical dimensions and specifications of this CBB60 motor run capacitor? A: This capacitor is rated for 250V AC and is available in common capacitance values of 30uF, 35uF, 40uF, and 50uF. It features a durable metal housing with an M8 threaded stud for secure mounting in appliances and machinery.. Q: How durable is this AC motor run capacitor for heavy-duty applications like an air compressor? A: The CBB60 capacitor is built for reliability in demanding environments. Its robust metal case and high-quality film dielectric are designed to withstand the heat and vibration typical in motors for air compressors, pumps, and washing machines.. Q: Can I use this 50uF capacitor to replace the one in my single-phase water pump motor? A: Yes, this capacitor is specifically designed as a motor run capacitor for single-phase AC motors. It is compatible with water pumps, air compressors, and washing machines, but you must always match the microfarad (uF) rating specified by your motor's manufacturer for safe and proper operation.. Q: Does this motor capacitor come with any warranty or guarantee? A: Yes, this product includes a standard manufacturer's warranty against defects in materials and workmanship. Please refer to the seller's specific warranty terms for detailed coverage duration and the process for any claims.. Q: Is this CBB60 capacitor a good value compared to other options? A: Yes, this offers excellent value for DIY enthusiasts and professionals seeking quality without premium brand pricing. It delivers reliable performance for regular use in common motor applications like pumps and compressors..
