The AQD19 Portable Strapping Machine delivers professional-grade tensioning and sealing for plastic strapping. This handheld pneumatic tool applies consistent, high-tension bands up to 16mm wide, securing heavy loads with a reliable friction weld seal. Its ergonomic design and lightweight construction ensure fatigue-free operation during extended packing sessions. Features and Benefits
- Pneumatic Tensioning System - Provides powerful, consistent tension up to 600N for secure, uniform banding on every pallet or package.
- Friction Weld Sealing Mechanism - Creates a strong, permanent seal without seals or clips, reducing consumable costs and ensuring a clean finish.
- Lightweight Ergonomic Body - Weighs under 3kg for easy maneuverability and reduced operator fatigue during high-volume strapping tasks.
- Adjustable Tension Control - Allows precise calibration for different materials and load requirements, from delicate bundles to rigid industrial pallets.
- Durable All-Metal Construction - Built with hardened steel components in critical areas for long-term reliability in demanding workshop or warehouse environments. Applications
- Pallet Stabilization for Shipping - Secure mixed-load pallets and unitized goods for safe transport and storage.
- Bundling Long or Awkward Items - Effectively group pipes, lumber, or extruded materials for handling and logistics.
- Corrugated Carton Closure - Reinforce heavy-duty boxes and crates where standard tape is insufficient.
- In-House Logistics and Warehousing - Ideal for manufacturing facilities, distribution centers, and print shops managing daily outbound shipments.
Dimensions: 360 x 140 x 110 mm. Net Weight: 2.8 kg. Strapping Material: Plastic/Polypropylene (PP) Band. Power Source: Compressed Air. Air Consumption: ≤ 0.1 m³/min. Air Pressure Requirement: 0.5 - 0.7 MPa. Cycle Time: ≤ 2.5 seconds. Hose Connection: 8 mm. Model: AQD19/AQD25. Noise Level: ≤ 75 dB(A). Operation: Handheld. Seal Type: Friction Weld. Strapping Width: 19 mm (AQD19), 25 mm (AQD25). Tension Force: 60 - 80 kg. Tension Method: Pneumatic. Type: Portable Pneumatic Strapping Machine. Dimensions (LxWxH): ~320 x 150 x 100 mm. Strapping Thickness Range: 0.5 mm to 1.2 mm (Typical). Strapping Width (AQD19 Model): 19 mm (0.75 inches). Strapping Width (AQD25 Model): 25 mm (1.0 inches). Tool Weight: Approximately 1.8 - 2.5 kg. Housing Material: Engineering Plastic (ABS/PC) and Aluminum Alloy. Strapping Material Compatibility: Polypropylene (PP) or Polyester (PET) Plastic Strapping. Power Source: Compressed Air (Pneumatic). Operating Temperature Range: 0°C to 40°C. Storage Temperature Range: -10°C to 60°C. Safety Features: Ergonomic Grip, Anti-Pinch Design, Locking Trigger. Air Inlet Connection: Standard 1/4" NPT or G1/4 Quick-Connect. Air Pressure Requirement: 0.5 - 0.7 MPa (70 - 100 PSI). Cycle Time: < 3 seconds per strap (Tension & Seal). Noise Level: < 85 dB(A) at 1 meter. Operation Method: Handheld, Manual Trigger. Product Name: AQD19/AQD25 Plastic Strapping Machine. Product Type: Portable Pneumatic Strapping Tool. Sealing Method: Friction Weld (Heat Seal). Tension Force: Adjustable via Regulator, Typical Range 50-150 kgf. Q: What are the key specifications and dimensions of the AQD19 portable strapping machine? A: This model is the AQD19, a handheld pneumatic baler designed for plastic strapping. While exact dimensions are not specified, it is a portable tool, and it is compatible with standard plastic strapping bands for packing and banding applications.. Q: How durable is this AQD19 plastic strapping tool for regular industrial use? A: The AQD19 is built as a robust, handheld pneumatic tool designed for material handling tasks. It offers reliable performance for consistent use in packing, wrapping, and banding operations, making it a dependable choice for workshops and warehouses.. Q: Can this AQD25 plastic strapping machine be used for securing heavy pallets? A: Yes, the AQD25 model is specifically designed as a pneumatic baler for applying tension to plastic strapping, making it ideal for securing loads on pallets. It is a common tool for industrial wrapping and packing of heavy or bulky items.. Q: Does this handheld strapping machine come with a warranty or guarantee? A: Warranty details are not specified for this product. We recommend contacting the seller directly for information on any applicable guarantee or support for the AQD19/AQD25 plastic strapping machine before purchase.. Q: Is the AQD19 portable strapping tool a good value compared to other brands? A: Yes, this offers excellent value for DIY enthusiasts and professionals seeking quality without premium brand pricing. It delivers reliable performance for regular use in banding, wrapping, and packing applications..
