SMD Schottky Diode Kit | MBR0520T1G, MBR0530T1G, MBR0540T1G | SOD-123 Package

Name: SMD Schottky Diode Kit | MBR0520T1G, MBR0530T1G, MBR0540T1G | SOD-123 Package
Brand: Compel Group
SKU: SEMI-00040
Price: 24.99 GBP
Availability: InStock

Stock Nr:

SKU:

1 / 3

£24.99inc VAT

Premium 100PCS MBR0520T1G MBR0530T1G MBR0540T1G SOD-123 MBR0520 MBR0530 MBR0540 SMD Schottky diode. Quality construction with reliable performance for professional and home use....

OptionSelect an option

Quantity

Secure checkout
All major cards
Tracked delivery

SMD Schottky Diode Kit | MBR0520T1G, MBR0530T1G, MBR0540T1G | SOD-123 Package

£24.99

Fast Shipping

Secure Payment

Easy Returns

Good to know

Questions about this product

What are these Schottky diodes mainly used for?: These SMD Schottky diodes are ideal for high-frequency switching applications, reverse polarity protection, and as freewheeling diodes. They offer reliable performance for both professional and home electronic projects.
How many diodes come in this kit and what types are they?: This kit includes 100 SMD Schottky diodes. You get a mix of MBR0520T1G, MBR0530T1G, and MBR0540T1G types, all in the compact SOD-123 package.
What materials are these diodes made from?: The diodes feature a copper lead frame and are encased in a molded plastic, halogen-free package. The terminals are plated with copper alloy for good conductivity and durability.

Semiconductors & ICs spec sheet (PDF)

Get a one-page sheet with full description, specifications, technical details, FAQs, price & SKU - handy to save, print, or share.

Not sure which one?

Compare with similar products

The same kind of product, in stock, in a similar price range.

This product: £24.99 · 4.0

This product

MBR0520T1G MBR0530T1G MBR0540T1G Schottky diode assortment in SOD-123 SMD package, 100 pieces on a labeled strip.
