What are fast recovery rectifier diodes used for?

These super ultra fast recovery rectifier diodes are designed for applications needing quick switching, such as in power supplies, inverters, and converters. Their ultra-low reverse recovery time (50-75ns) helps improve efficiency in high-frequency circuits.

Will this diode work in my existing circuit board?

This diode comes in a DO-214AC (SMA) package, which is a surface mount type. Ensure your circuit board is designed for surface mount components and has the correct footprint for this package. It handles an average forward current of 1A and can withstand repetitive peak reverse voltages of 600V or 1000V depending on the specific variant (US1J or US1M).

What are the temperature limits for this rectifier diode?

The diode can operate in an operating junction temperature range from -55 °C to +150 °C. It also has the same storage temperature range, ensuring reliability in various thermal conditions.

Fast Recovery Rectifier Diode | 1A 600V-1000V | US1J US1M SMA DO-214AC | Ultra-Low Reverse Recovery

Name: Fast Recovery Rectifier Diode | 1A 600V-1000V | US1J US1M SMA DO-214AC | Ultra-Low Reverse Recovery
Brand: Compel
SKU: SEMI-00039
Price: 5.95 USD
Availability: InStock

Stock #:TBS-02837

SKU:SEMI-00039
