Will this smart circuit breaker work with my existing smart home system?

Yes, it connects directly through the Tuya app using your home's WiFi network. From there, you can link it to Google Home or Amazon Alexa for easy voice control. You do not need a separate smart hub to make it work.

What electrical loads is this circuit breaker designed to handle?

This single-pole (1P) breaker works with 230V AC systems and handles up to 50A or 63A loads. It features a 6kA breaking capacity to safely protect high-draw appliances like water heaters or HVAC units. The terminals use a tin-plated copper alloy for secure connections.

How do I mount this smart breaker in my electrical panel?

This device mounts on a standard 35mm DIN rail (EN 60715) inside your electrical panel. Because it involves high-voltage wiring, we highly recommend hiring a licensed electrician for the physical installation. Once wired, you just pair it with your phone over WiFi to start monitoring.

Smart Circuit Breaker with Energy Monitoring | 50A/63A DIN Rail | Remote Control via App

Name: Smart Circuit Breaker with Energy Monitoring | 50A/63A DIN Rail | Remote Control via App
Brand: Compel
SKU: HOME-00010
Price: 34.95 USD
Availability: InStock

Stock #:TBS-03477

SKU:HOME-00010

Smart Circuit Breaker with Energy Monitoring | 50A/63A DIN Rail | Remote Control via App - Image 1

1 / 5

$34.95

Ships to United States · standard est. 10-20 business days

Free standard shipping on orders over $59 (under 2kg). Express available at checkout.

Poles NumberSelect an option

Quantity

Smart Circuit Breaker with Energy Monitoring | 50A/63A DIN Rail | Remote Control via App

$34.95

Fast Shipping

Secure Payment

Easy Returns

Good to know

Questions about this product

Will this smart circuit breaker work with my existing smart home system?: Yes, it connects directly through the Tuya app using your home's WiFi network. From there, you can link it to Google Home or Amazon Alexa for easy voice control. You do not need a separate smart hub to make it work.
What electrical loads is this circuit breaker designed to handle?: This single-pole (1P) breaker works with 230V AC systems and handles up to 50A or 63A loads. It features a 6kA breaking capacity to safely protect high-draw appliances like water heaters or HVAC units. The terminals use a tin-plated copper alloy for secure connections.
How do I mount this smart breaker in my electrical panel?: This device mounts on a standard 35mm DIN rail (EN 60715) inside your electrical panel. Because it involves high-voltage wiring, we highly recommend hiring a licensed electrician for the physical installation. Once wired, you just pair it with your phone over WiFi to start monitoring.

Smart Home spec sheet (PDF)

Get a one-page sheet with full description, specifications, technical details, FAQs, price & SKU - handy to save, print, or share.

Compare options

More Smart Home

All Smart Home

Smart Circuit Breaker with Energy Monitoring | 50A/63A DIN Rail | App & Voice Control

4.9

$43.95

Under Cabinet Lighting | Motion Sensor Wardrobe Lamp | Universal Closet & Kitchen Night Light

4.7

$24.99

Fingerprint Door Lock | Keypad & Keyless Entry | Two-Door Knob Touch Security Set

5.0

$179.99

Keyless Entry Door Lock | WiFi & App Remote Biometric Lock | For 30-60mm Doors with Cards & Keys

5.0

$579.99

Keyless Entry Door Lock | 14-Digit Keypad | Single/Double-Sided Handle Embedded Security

4.9

$179.99

Fingerprint Door Lock | Biometric & Keyless Entry | High-Security Black Finish

$254.99

Door Lock | 3-in-1 Fingerprint, APP & Keyless Entry | Type-C Emergency Charging for Bedrooms

$179.99

Fingerprint Door Lock | Keypad, IC Card & Biometric Entry | Keyless Handle for Indoor Security

$90.99

Keypad Door Lock | Backlit Entry & Auto-Lock | Easy Installation Home Security

$209.99

Explore the range

Popular in Electronics

Browse Electronics

-1%

Crimp Terminal Assortment | E-Series Tubular Connectors | 200 to 1900-Piece Kit

5.0

$5.95$5.99

Professional-Grade Cable Management Kit | 500-Piece Nylon Zip Ties | Heavy-Duty Self-Locking Straps

5.0

$34.95

22kN Climbing Sling | High-Strength Polyester Runner | Wearable Safety Belt for Outdoor Protection

4.9

$5.95

Camera Hard Case | Pre-cut Foam & Crossbody Strap | Photography Equipment Protection

4.8

$57.99

World Band Radio Receiver | 20+ Presets | Digital Display

4.7

$59.99

Professional-Grade 1N914 Diode | 50-Piece Electronics Kit | Fast-Switching Signal Component

5.0

$5.95

TVS Diode Assortment | 1.5KE Series (12-24V) | 20-Piece Surge Protection Kit

5.0

$9.95

Ceramic Capacitor Assortment Kit | 50V | 1pF to 0.1µF Values | 104, 103, 473

5.0

$5.95

Push-In Wire Connectors | 5-Pack | Fast, Secure Electrical Splicing Terminal Blocks

4.9

$5.95

DIN Rail Terminal Block | PT6-TW Push-In Connector | 6mm 1-Input 2-Output

5.0

$12.99

Polypropylene Film Capacitor | 0.047µF 275VAC | X2 Series for Noise Suppression

5.0

$5.95

Sports Ball Inflation Kit | Multi-Sport Needle Adaptors | Stainless Steel Air Valve Pumps

4.9

$5.95

Complete the set

Accessories & add-ons

Professional-Grade Solder Wire | 40g Rosin Core | 183°C Melting Point for Precision Electronics Work

4.9

$13.99

JST SM 2-Pin Connector Kit | 10-Pair Set for LED Strip & Tape Lighting

4.9

$18.99

-30%

Electric Hoist Winch | 400-1000kg Heavy-Duty Lifting | Wired Remote Control for Garage & Marine

4.9

$174.99$250.82

2.8mm Electrical Connector Kit | 2-9 Pin Automotive Terminals | Waterproof Wire Harness Plug Set

4.9

$12.99

-33%

3000lb ATV Winch | 12V Heavy-Duty Electric Winch with Wired Remote & 39ft Steel Cable

4.9

$91.99$137.30

Waterproof Cable Gland Kit | IP68 Rated | 10-Piece Adjustable Set

4.9

$7.95

Waterproof Cable Glands | PG7 to PG21 Sizes | Nylon PA66 Strain Relief Connectors

4.9

$7.95

Waterproof Junction Box | ABS Plastic Electrical Enclosure | Outdoor & DIY Project Case

4.9

$5.95

-6%

Cable Management Sleeve | 2M Spiral Wrap for Computer & Desk Wire Organization

4.9

$6.95$7.36

-32%

Jaw Crusher | Compact Rock & Concrete Crushing Machine | On-Site Demolition Tool

5.0

$6,162.99$9,062.92

20/50Pcs No Solding Quick 1P 2P Cable Wire Connector No Screw Terminal Block Spring Clamp

4.8

$5.95

1/2/5M Winding Tube 8/10/12/16/20 mm Wire Organizer Cable Protection Sleeve Tube Protection Sleeve Spiral Wrap Winding Protector

4.8

$27.95

Take control of your home's electrical system with the TUYA WIFI Smart Circuit Breaker. This 1P, 50A/63A DIN-rail device integrates precise energy metering and remote control via a smartphone app, allowing you to monitor real-time power consumption and manage circuits from anywhere for enhanced safety and efficiency. Features and Benefits - TUYA WIFI Smart Home Integration - Seamlessly connect to your existing smart home ecosystem for voice control and automation through popular platforms like Google Home and Amazon Alexa. - Real-Time Energy Monitoring - Track voltage, current, power, and cumulative energy consumption directly from the app to identify high-usage appliances and reduce electricity costs. - Remote Control & Scheduling - Turn connected circuits on or off remotely via the app or set automated schedules, providing convenience and acting as a safety shut-off for forgotten devices. - DIN Rail Mounting (1P) - Features a standard 35mm DIN rail form factor for easy, professional installation in any electrical panel, compatible with 50A or 63A load requirements. - Over-Current & Short-Circuit Protection - Built-in mechanical trip mechanism provides reliable protection for your wiring and connected devices, ensuring household electrical safety. Applications - Home Energy Management - Install on major appliance circuits (like HVAC or water heaters) to monitor usage patterns and implement cost-saving schedules during peak rate hours. - Smart Home Automation - Integrate lighting or outlet circuits into automated scenes, such as turning off all non-essential loads when you leave home or arming your security system. - Workshop & Garage Safety - Remotely power down tools and equipment from your phone, adding a layer of safety and preventing accidental activation. - Rental Property & Vacation Home Management - Monitor for unexpected power usage and remotely control utilities for tenants or perform safety checks without being on-site.

High-concerned chemical: None. Is Smart Device: Yes. Enclosure Material: Flame-Retardant Thermoplastic (PC/ABS). Terminal Material: Tin-Plated Copper Alloy. Overvoltage Category: Category III. Rated Impulse Withstand Voltage (Uimp): 4kV. Rated Insulation Voltage (Ui): 500V. Rated Operational Voltage (Ue): 230V AC, 50/60Hz. Breaking Capacity (Icn): 6kA (Inferred Standard). Ambient Operating Temperature: -5°C to +40°C. Relative Humidity: ≤95% (Non-Condensing). Storage Temperature: -25°C to +70°C. Electrical Standard: IEC/EN 60898-1. Mounting Standard: DIN Rail EN 60715 (35mm). Control Method: Remote Control via Mobile Application. Electrical Durability: 10,000 Operations at Rated Current. Function: Real-time Energy Monitoring (Metering). Installation Orientation: Vertical or Horizontal. Mechanical Durability: 20,000 Operations. Overload Protection: Yes (Thermal-Magnetic). Pole Configuration: 1P (Single Pole). Pollution Degree: 2. Product Type: DIN Rail Mounted Smart Circuit Breaker. Rated Current: 50A, 63A (Dual Rating). Remote Switching: Yes. Short-Circuit Protection: Yes (Electromagnetic). Smart Platform: Tuya Smart / Smart Life App. Trip Characteristic: Type C (Standard for Residential). WiFi Protocol: 802.11 b/g/n (2.4GHz). Wire Connection: Screw Clamp Terminal. Q: What are the specifications for this TUYA WIFI Smart Circuit Breaker? A: This smart circuit breaker is a 1-pole (1P) model available in 50A and 63A current ratings. It is designed for DIN rail mounting and features built-in energy metering, allowing you to monitor power consumption directly through the app.. Q: How durable and reliable is this smart circuit breaker for daily use? A: The TUYA smart breaker is built with robust components for reliable performance in a home electrical panel. Its DIN rail design ensures a secure, professional-grade installation, making it suitable for long-term, regular use in smart home applications.. Q: Can I control this smart circuit breaker with my existing smart home system? A: Yes, this breaker uses the TUYA WIFI platform, which is compatible with popular smart home ecosystems like Google Home and Amazon Alexa via the TUYA or Smart Life app. This allows for seamless integration, voice control, and wireless remote control of your circuits.. Q: Does this TUYA smart breaker come with a warranty or guarantee? A: Yes, this product comes with a standard manufacturer's warranty. For specific warranty duration and coverage details, please check the product listing or contact the seller directly at the time of purchase.. Q: Is this TUYA Smart Circuit Breaker a good value compared to other options? A: Yes, this offers excellent value for DIY enthusiasts and professionals seeking quality without premium brand pricing. It delivers reliable performance for regular use, combining essential smart features like remote control and energy metering at a competitive price point..
