The iYeah Classical CUT50X CUT50D Air Plasma Cutter delivers professional-grade cutting power with its dual 110V/220V 50A capability. It cleanly slices through steel up to 16mm thick, offering exceptional versatility for demanding fabrication and repair tasks in any workshop environment. Features and Benefits
- Dual Voltage 110V/220V Operation - Use it in a home garage on standard 110V or connect to 220V power for maximum 50A output and full 16mm cutting capacity on industrial sites.
- 50A Plasma Cutting Torch - Generates a high-temperature plasma arc for fast, clean cuts with minimal slag and a narrow kerf, reducing material waste and post-cut cleanup.
- High-Frequency Pilot Arc Start - Reliably initiates the plasma arc even on painted, rusty, or uneven surfaces without direct contact, preventing torch tip damage.
- Adjustable Current Control - Fine-tune the amperage from 20A to 50A to match the cutting speed and precision to the material thickness, optimizing performance and consumable life.
- Integrated Air Pressure Regulator & Gauge - Maintains consistent air flow for stable plasma arc and clean cuts, with easy monitoring for optimal operation.
- Robust Metal Housing - Provides durable protection for internal components against workshop dust, debris, and accidental impacts, ensuring long-term reliability. Applications
- Metal Fabrication & Repair - Ideal for cutting sheet metal, plates, pipes, and structural steel for custom projects, automotive repair, or equipment maintenance.
- Construction & Site Work - Portable design and dual voltage make it perfect for on-site installation of HVAC ducting, metal framing, and modifying structural components.
- DIY & Home Workshop Projects - A powerful, value-focused tool for hobbyists creating metal art, furniture, or performing vehicle restoration with professional results. Note
This machine requires a compatible air compressor (minimum 60 PSI, 4 CFM) and dry, clean, oil-free air to operate correctly and maintain warranty coverage. Always consult the manual for proper setup and safety procedures.
Open Circuit Voltage: 240V. Dimensions: 400 x 180 x 300 mm. Net Weight: 9.5 kg. Input Voltage: 110V / 220V AC. Air Flow Requirement: 60 L/min. Air Pressure Requirement: 0.4 - 0.6 MPa. Cooling Method: Forced Air. Cutting Current Range: 10A - 50A. Duty Cycle: 60% @ 50A. Insulation Class: F. Maximum Cutting Thickness: 16 mm. Model Number: CUT50X, CUT50D. Pilot Arc Current: 5A. Product Type: Air Plasma Cutter. Protection Class: IP21S. Rated Input Current: 50A. Dimensions (Approx.): 480 x 230 x 390 mm (L x W x H). Weight (Approx.): 15 kg. Case Material: Powder-Coated Steel. Suitable Cutting Materials: Mild Steel, Stainless Steel, Aluminum, Copper. Input Voltage: Dual Voltage 110V / 220V AC. Open Circuit Voltage: ~240-300V DC. Maximum Cutting Capacity (Mild Steel): 16 mm (5/8 inch). Maximum Cutting Speed (for 16mm mild steel): ~400 mm/min. Maximum Output Current: 50A. Rated Output Current: 50A. Recommended Air Compressor Capacity: Minimum 2 HP. Cutting Method: Non-Contact Pilot Arc (High Frequency Start). Duty Cycle @ Rated Current: 60% (Based on 10-minute cycle at 40°C ambient). Model Number: CUT50X / CUT50D. Pilot Arc Current: ~20-30A. Product Type: Air Plasma Cutter. Protection Class: IP21S. Rated Input Current: 50A. Required Air Flow: Minimum 140 L/min (5 CFM). Required Air Supply Pressure: 4.5 - 5.5 bar (65 - 80 PSI). Thermal Protection: Automatic Overheat Shutdown. Torch Connection Type: Quick-Disconnect. Torch Type: Handheld Air-Cooled Plasma Torch. Q: What are the exact dimensions and weight of the iYeah CUT50X plasma cutter? A: The product specifications provided do not list the dimensions or weight. For precise measurements, please check the product listing's detailed specifications or contact the seller directly.. Q: How durable is the iYeah CUT50D plasma cutter for regular workshop use? A: The iYeah CUT50D is built with a robust metal housing and quality components designed for durability. It offers reliable performance for DIY projects and professional workshop tasks with proper maintenance.. Q: Can the iYeah CUT50X plasma cutter be used on both 110V and 220V power sources? A: Yes, the iYeah CUT50X is a dual voltage plasma cutter, compatible with both 110V and 220V power supplies. This flexibility allows you to use it in various workshop and job site environments.. Q: Does the iYeah CUT50D plasma cutter come with a warranty? A: Warranty details are not specified in the provided product information. It is recommended to review the seller's warranty policy on the product page or inquire with them before purchase.. Q: Is the iYeah CUT50X plasma cutter a good value for its cutting capacity? A: Yes, this offers excellent value for DIY enthusiasts and professionals seeking quality without premium brand pricing. It delivers reliable performance for regular use, with a 50A output capable of cutting up to 16mm thick metal..
