What kind of cables can I use with these mini XLR connectors?

These mini XLR connectors are designed for cables with an outer diameter between 3mm and 6mm. The solder-type terminals allow you to create custom cable assemblies for your specific audio or video needs.

What are these 3-pin mini XLR connectors primarily used for?

These 3-pin mini XLR connectors are excellent for repairing or building custom cables for microphones and headsets. They're also suitable for connecting multi-channel audio equipment in studios or for live sound, and for wiring control signals in specialized AV gear.

What are these mini XLR connectors made from?

The shell of these connectors is made from zinc alloy, which provides physical protection and shields against radio frequency interference. The pins are gold-plated copper, ensuring good conductivity and resistance to corrosion for a long service life.

XLR Aviation Connector | 3-Pin Male & Female Plug | Microphone Audio Socket

Name: XLR Aviation Connector | 3-Pin Male & Female Plug | Microphone Audio Socket
Brand: Compel
SKU: SPAR-00034
Price: 19.99 USD
Availability: InStock
Rating: 4.8 (20 reviews)

Stock #:CMP-02060

SKU:SPAR-00034

XLR Aviation Connector | 3-Pin Male & Female Plug | Microphone Audio Socket - Image 1

1 / 6

$19.99

Ships to United States · standard est. 10-20 business days

Free standard shipping on orders over $59 (under 2kg). Express available at checkout.

ColorSelect an option

Package QuantitySelect an option

PinsSelect an option

Quantity

XLR Aviation Connector | 3-Pin Male & Female Plug | Microphone Audio Socket

$19.99

Fast Shipping

Secure Payment

Easy Returns

Good to know

Questions about this product

What kind of cables can I use with these mini XLR connectors?: These mini XLR connectors are designed for cables with an outer diameter between 3mm and 6mm. The solder-type terminals allow you to create custom cable assemblies for your specific audio or video needs.
What are these 3-pin mini XLR connectors primarily used for?: These 3-pin mini XLR connectors are excellent for repairing or building custom cables for microphones and headsets. They're also suitable for connecting multi-channel audio equipment in studios or for live sound, and for wiring control signals in specialized AV gear.
What are these mini XLR connectors made from?: The shell of these connectors is made from zinc alloy, which provides physical protection and shields against radio frequency interference. The pins are gold-plated copper, ensuring good conductivity and resistance to corrosion for a long service life.

Spark Plug Sockets spec sheet (PDF)

Get a one-page sheet with full description, specifications, technical details, FAQs, price & SKU - handy to save, print, or share.

Compare options

More Spark Plug Sockets

All Spark Plug Sockets

Explore the range

Popular in Automotive & Powersports

Browse Automotive & Powersports

-57%

Brake Caliper Piston Rewind Tool | Disc Brake Pad Replacement Kit | Heavy-Duty Service Cube

5.0

$8.95$20.68

Motorcycle Chain Maintenance Kit | Mess-Free Lubricator & Cleaner | 1-3 Set Options

5.0

$4.49

Professional-Grade 3M Double-Sided Mounting Tape | 300cm Heavy-Duty | No-Residue Removal

4.9

$6.95

TB2 PRO Mini Tyre Inflator | 120PSI Cordless Pump | Fast Charge, Screen Display

4.9(3.5K)

$88.99

OBD2 Scanner Diagnostic Tool | Voltage & Battery Test | V500 Code Reader

4.9

$26.95

Car Air Pump for Car | 150PSI Portable Tyre Inflator | Motorcycle & Bicycle

4.9(3.7K)

$46.95

Pads and Rotors Themed Car Vent Clips | Mini Drum Cymbals | Universal

4.9(775)

$16.99

12V Car Battery Charger & Maintainer | Pulse Repair Mode | Moto & Truck

4.9(1.5K)

$16.99

12V Car Battery Charger | 2A Pulse Repair for Moto & Truck | LED Display

4.9(1.3K)

$47.95

Plug Gap Tool | Double Hole Spanner | Engine Repair Socket Wrench

4.9(726)

$42.95

Microfiber Cloths | 40x40cm Thick Car Detailing Towels | Auto Wash Drying

4.9(5.8K)

$11.99

Brake Bleeder Kit | 1L & 0.75L Capacity | Car & Motorcycle Use

4.7(1.9K)

$39.95

Complete the set

Accessories & add-ons

-24%

Marine-Grade Switch Panel | 4/6/8-Gang Digital Display with USB Port | 12V Waterproof for Boats & RVs

5.0

$84.99$112.15

-59%

6-Gang Marine-Grade Switch Panel | 12V Waterproof Rocker Switches with Red LED Illumination

5.0

$5.95$14.47

-48%

Marine-Grade Rocker Switch Panel | 2-8 Circuit Control | Waterproof Toggle Panel for Boats & RVs

5.0

$41.95$80.35

-54%

8-Gang Marine Switch Panel | 12V/24V Power Distribution | USB Charging for RV, Boat & Van

5.0

$8.95$19.57

Tesla Jack Pads | 4-Piece Set for Model 3, Y, S, X | Protective Chassis Lift Adapters

4.9

$29.95

20A Marine-Grade Joystick Switch | 12V Waterproof Panel for Boats, RVs & Trucks

4.9

$7.95

-4%

Marine & RV Touch Switch Panel | 12V/24V Relay System | 6-12 Gang Slim Control Box

5.0

$166.99$173.79

Marine-Grade Rocker Switch Panel | 1-4 Gang Toggle | 12V/USB Power | Blue LED Backlit

4.9

$19.99

Tesla Jack Pad Set | 4-Pack Rubber Pucks with Protective Storage Case

4.9

$55.99

Wireless Winch Remote Control Electric Winch Controller with 434MHZ Receiver for Truck ATV Winch Remote Control

5.0

$40.95

-28%

Marine-Grade Switch Panel | 12V/24V Touchscreen Control with USB Charger & Voltmeter

5.0

$61.99$86.63

Heavy-Duty Tyre Pressure Gauge | 10-150 PSI | Dual Head Truck Tool

4.9(172)

$21.95

This 6-pin mini XLR connector provides a secure link for audio and video equipment. The zinc alloy shell and copper pins ensure a clean signal transfer. It’s a specialized connector, essential for its specific job. Features and Benefits - Zinc Alloy Shell - Offers physical protection and shields against radio frequency interference. - Gold-Plated Copper Pins - Ensure good conductivity and resist corrosion for a long service life. - Solder-Type Terminals - Allow you to create strong, custom cable assemblies for specific needs. - Compact Mini XLR Form - Fits into tight spaces where a standard-sized XLR plug is too large. Applications - Repairing or building custom cables for microphones and headsets. - Connecting multi-channel audio equipment in recording studios or for live sound. - Wiring control signals for lighting rigs and other specialized AV gear.

Socket Size: Not Applicable. Material: Zinc Alloy, Copper Pins. Battery Included: No. Wireless Functionality: No. Application: Microphone Audio Video Connecting. Connector Type: Mini XLR. Gender: Female Plug, Male Socket. Pin Configuration: 3/4/5/6-pin. Pin Material: Copper. Shell Material: Zinc Alloy. Battery Included: No. EU LVD Voltage: Low Voltage. Rated Voltage: 50 V. Wireless Functionality: No. Cable Compatibility: Suitable for cables with outer diameter 3mm-6mm. Connector Type: Mini XLR Aviation Connector. Contact Plating: Gold-plated. Contact Resistance: ≤5 mΩ. Durability: 1000 mating cycles. Gender: Female Plug, Male Socket. Insulation Resistance: ≥100 MΩ. Mounting Type: Panel Mount / Cable Mount. Pin Configuration: 3-pin, 4-pin, 5-pin, 6-pin. Product Name: 3/4/5/6pin Mini XLR Aviation Connector Female Plug Male Socket Zinc Alloy+copper pins for MIC Microphone Audio Video Connecting. Rated Current: 5 A. Q: What are the pins made of and how many are there? A: These are Mini XLR connectors and you can choose between 3, 4, 5, or 6 pin configurations. The pins themselves are copper for good conductivity, and they are housed in a zinc alloy shell.. Q: What are the pins made of and how many are there? A: These are Mini XLR connectors and you can choose between 3, 4, 5, or 6 pin configurations. The pins themselves are copper for good conductivity, and they are housed in a zinc alloy shell.. Q: How secure is the connection? Will it pull apart easily? A: The female plug has a push-button latching system that locks it securely to the male socket. It creates a solid connection that won't come loose accidentally during use.. Q: How secure is the connection? Will it pull apart easily? A: The female plug has a push-button latching system that locks it securely to the male socket. It creates a solid connection that won't come loose accidentally during use.. Q: What kind of cable diameter do these connectors fit? A: These are designed for smaller cables, typically used in microphones, headsets, and some audio equipment. They will accommodate a cable with an outer diameter up to 5mm.. Q: What kind of cable diameter do these connectors fit? A: These are designed for smaller cables, typically used in microphones, headsets, and some audio equipment. They will accommodate a cable with an outer diameter up to 5mm.. Q: Do you stand behind these connectors if there's an issue? A: Absolutely. They come with a 1-year warranty against any manufacturing defects. If a connector fails under normal use, we will replace it.. Q: Do you stand behind these connectors if there's an issue? A: Absolutely. They come with a 1-year warranty against any manufacturing defects. If a connector fails under normal use, we will replace it.. Q: I saw this listed under automotive parts. Can I use this as a spark plug socket or for car wiring? A: No, this is a Mini XLR connector for audio and video signals, not an automotive part. It's not designed to be a spark plug socket or handle the voltage and heat found in a car engine.. Q: I saw this listed under automotive parts. Can I use this as a spark plug socket or for car wiring? A: No, this is a Mini XLR connector for audio and video signals, not an automotive part. It's not designed to be a spark plug socket or handle the voltage and heat found in a car engine..
