35mm Concealed Hinge Jig Kit | Professional Boring & Drilling Guide | For Face Frame Cabinet Tools
Stock #:CMP-00984
SKU:ACCS-00541
1 / 3
$14.99
Ships to United States · standard est. 10-20 business days
Free standard shipping on orders over $59 (under 2kg). Express available at checkout.
10-24 units-10%
Save $14.99 on 10 units
$13.49
per unit
25-49 units-15%
Save $56.21 on 25 units
$12.74
per unit
50-99 units-18%
Save $134.91 on 50 units
$12.29
per unit
100+ units-20%
Save $299.80 on 100 units
$11.99
per unit
Click a tier to set quantity • Discount applies automatically at checkout
Achieve flawless, professional results in cabinet installation with this precision 35mm concealed hinge jig kit. This essential tool guides your drill for perfectly aligned hinge cups, ensuring smooth...
Select an option
1
$14.99
1
Fast Shipping
Secure Payment
Easy Returns
Good to know
Questions about this product
- Will this jig work with standard European hinges from major hardware brands?
- Yes, it works with standard European-style concealed hinges from most major brands. It is designed specifically for face frame cabinets and cupboards. You can use it with any standard 35mm Forstner or hinge boring bit.
- What parts do I actually get in this package?
- The box contains the 8mm thick jig plate, a depth stop, centering pins, and mounting hardware. It does not include the 35mm drill bit, so you will need to supply your own Forstner bit.
- Can I adjust the depth of the hole so I don't drill all the way through my cabinet door?
- Yes, the kit features an adjustable depth stop to control how deep your drill bit goes. This prevents blow-through and protects your cabinet face material from damage. You can easily set it to match your specific hinge cup depth.
