The DEWALT DCH263 20V Brushless Cordless Rotary Hammer delivers professional-grade power for demanding concrete drilling. Its brushless motor provides up to 2.1 Joules of impact energy for efficient drilling in concrete, brick, and masonry. The cordless design offers complete jobsite mobility without sacrificing performance. Features and Benefits
- 20V MAX Brushless Motor - Delivers more runtime and power from each battery charge with increased durability and no maintenance.
- 2.1 Joules of Impact Energy - Provides the force needed for fast, clean drilling in tough materials like reinforced concrete.
- SDS-Plus Chuck System - Allows for quick, secure bit changes without tools and efficient power transfer to the bit.
- D-Handle Design with Vibration Control - Offers superior balance and control during overhead or extended use, reducing user fatigue.
- Variable Speed Trigger and Selector Switch - Enables precise control for drilling, hammer drilling, or rotation-only modes for various tasks. Applications
- Core Drilling and Anchor Setting - Ideal for installing electrical boxes, plumbing lines, and heavy-duty fasteners in concrete walls and floors.
- Demolition and Chiseling Tasks - Handle light chipping, chasing, and breaking with the dedicated hammer-only function.
- Overhead and Confined Space Work - The cordless, compact D-handle design provides freedom of movement in tight areas or on ladders. Note
Tool only, battery and charger sold separately. Backed by a 3-year limited warranty and 1-year free service contract.
Maximum Drilling Capacity (Concrete): 26 mm. Maximum Drilling Capacity (Steel): 13 mm. Maximum Drilling Capacity (Wood): 32 mm. Battery System: DEWALT 20V Max. Battery Included: No. Voltage: 20V Max. Brand: DEWALT. Charger Included: No. Drive System: SDS-Plus. Handle Type: D-Handle. Impact Energy: 2.1 J. Model: DCH263. Motor Type: Brushless. No-Load Impact Rate: 0-4,600 BPM. No-Load Speed: 0-1,100 RPM. Product Type: Cordless Rotary Hammer. Reverse Function: Yes. Tool-Free Bit Change: Yes. Variable Speed Trigger: Yes. Vibration Control: Yes. Tool Length: 17-3/4 inches (451 mm). Tool Weight (without battery): 7.3 lbs (3.3 kg). Impact Energy (EPTA): 2.1 Joules (inferred from model series). Power Source: DEWALT 20V MAX Lithium-Ion Battery Platform (Tool Only). Maximum Drilling Capacity (Concrete): 5/8 inch (16 mm). Maximum Drilling Capacity (Steel): 1/2 inch (13 mm). Maximum Drilling Capacity (Wood): 1-1/8 inch (29 mm). No-Load Speed: 0-1,100 RPM (inferred from model series). Operation Modes: Rotary Hammer, Hammer Only, Drill Only. Bit Retention: Spring-loaded SDS-Plus chuck. Chuck Type: SDS-Plus. Dust Management: Integrated dust seal for cleaner operation. Handle Design: D-Handle with Side Assist Handle. Mechanism: Electropneumatic Hammer Mechanism. Motor Type: Brushless Electric Motor. No-Load Impact Rate: 0-5,100 BPM (inferred from model series). Product Type: Cordless SDS-Plus Rotary Hammer Drill. Vibration Control: Active Vibration Control (AVC) System. Q: What are the key specifications for the DEWALT DCH263 SDS Rotary Hammer? A: The DEWALT DCH263 is a 20V MAX cordless SDS rotary hammer drill. It features a brushless motor for efficiency and durability, and it operates using the brand's 20V battery platform (battery sold separately). The model number is DCH263, and it has a D-handle design for improved control.. Q: How durable is the DEWALT DCH263 cordless hammer drill for professional use? A: Built to DEWALT's professional-grade standards, the DCH263 is highly durable. Its brushless motor is engineered for longer life and reduced maintenance, making it suitable for demanding job site conditions and frequent concrete drilling tasks.. Q: Can the DEWALT DCH263 be used for drilling into reinforced concrete? A: Yes, the DEWALT DCH263 SDS rotary hammer is specifically designed for drilling into tough materials like concrete, brick, and masonry. Its hammering action combined with rotation makes it effective for creating holes in reinforced concrete for anchors, rebar, and conduit.. Q: What is the warranty on the DEWALT DCH263 power tool? A: DEWALT tools typically come with a strong warranty, though specific terms can vary. For exact warranty details on the DCH263, including its length and what it covers, please check the official DEWALT documentation or contact their customer service directly.. Q: Is the DEWALT DCH263 a good value compared to other cordless SDS hammers? A: As a professional-grade tool from a leading brand, the DCH263 offers excellent value through long-term reliability and performance. Its brushless motor and compatibility with the extensive 20V battery system provide efficiency and versatility that justify the investment for serious users..
